SPECIFICHE TECNICHE
Frame
Trekking 28″ Alloy 6061 135mm QR Integrated battery
Seat Post
SIGNUM Alloy Black 30,9x350mm
Stem
SIGNUM Alloy Adjustable 25.4
Shift Lever
SHIMANO Altus SL-M315 8speed
Cassette
SHIMANO CS-HG20 12-32 8 speed
Tyres
CST C1698 28″ x 1.75
Rear Carrier
SIGNUM Alloy Rear Carrier 28″
Lights
Front : AXA Pico 30Lux 6V controlled by display Rear : AXA Spark Steady light controlled by display
Drive Unit
BAFANG M200 Mid motor 65Nm Torque
Battery
MINI Intube Battery 36v, 504Wh/14ah with BMS
Fork
ZOOM CH141 Suspension fork 28″ travel 55mm
Handlebar
SIGNUM Alloy Black 600mm
Rear Derailleur
SHIMANO Acera RD-M360 8speed
Crankset
BAFANG 44T crank 170mm
Wheels
SIGNUM Alloy 32h 28″+ β SHIMANO TX505 Hubs
Brakes
SHIMANO MT200 Hydraulic Disc Brake Rotor 160-160
Kickstand
URSUS Alloy
saddle
SIGNUM Trekking Comfort line
Display
BAFANG DP E161 full function set w/bluetooth system
